Tersun

Download PDF data sheet
Photo coming soon

Particulars

Owner: unknown

Designer: Dolsar

Contractor: unknown

Statistics

Type: Gravity

Purpose(s): Irrigation

Reservoir capacity: 9 m3x106

Height: 54 metres

Length: 273 metres

Volume of RCC: 205 m3x103

Total volume: unknown

Construction Dates

Start of Project: /16 ( 2016)

Start of RCC: /20 ( 2020)

End of RCC: /22 ( 2022)

End of Project: /24 ( 2024)

Country: Turkey

River: Tersun

DMS Co-ordinates: 40˚12'40.9"N, 39˚15'22.55"E

DD Co-ordinates: 40.211361, 39.256264

Facings

Upstream

SlopeType
0.05Traditional concrete against formwork

Downstream

SlopeType
0.80Traditional concrete against formwork

Spillway

SlopeType


Placement

Layers (mm)Lifts (mm)


Cementitious material

Cement (kg/m3)

Pozzolan (kg/m3)Pozzolan Type
