Caculo-Cabaça

Download PDF data sheet
Photo coming soon

Particulars

Owner: unknown

Designer: COBA

Contractor: CGGC & Voith J.V.

Statistics

Type: Gravity

Purpose(s): Hydropower

Reservoir capacity: 436 m3x106

Height: 103 metres

Length: 553 metres

Volume of RCC: 1075 m3x103

Total volume: 1450 m3x103

Construction Dates

Start of Project: 08/17 (August 2017)

Start of RCC: /20 ( 2020)

End of RCC: /23 ( 2023)

End of Project: 03/24 (March 2024)

Country: Angola

River: Kwanza

DMS Co-ordinates: 9˚46'48"S, 14˚32'56.4"E

DD Co-ordinates: -9.780000, 14.549000

Facings

Upstream

SlopeType
Vertical

Downstream

SlopeType
0.85

Spillway

SlopeType
0.85

Placement

Layers (mm)Lifts (mm)
3002400

Cementitious material

Cement (kg/m3)
100
Pozzolan (kg/m3)Pozzolan Type
0
